03S Series Professional Monitor

Products Details

Product Specifications
03S Series Professional MonitorDifference contrast
  •
  •   Model W3203S W3203SH(AUO OC) W3203SH Q3203S
  •   Panel size 32" 32" 32" 32"
  • Display parameters Backlight category ELED edge Type   ELED edge Type   ELED edge Type   ELED edge Type
  •   Panel FHD IPS   FHD VA   FHD VA   QHD IPS
  •   Aspect ratio 16:9   16:9   16:9   16:9
  •   Color Gamut 68%NTSC   72%NTSC   16.7M   72%NTSC(85%Optional)
  •   Resolution 1920*1080   1920*1080   1920*1080   2560*1440
  •   Resfresh rate 60Hz   144Hz   144Hz   60Hz
  •   Viewing angle H:178°/V:178°(CR>10)   H:170°/V:170°(CR>10)   H:178°/V:178°(CR>10)   H:178°/V:178°(CR>10)
  •   Brightness 300-350cd/m²   250-300cd/m²   250-300cd/m²   250-300cd/m²
  •   Contrast ratio 1400:1   4000:1   3000:1   1200:1
  •   Response time 8ms   6.5ms   21ms   8ms
  •   Response time(With OD) 6.5ms   2.5ms   5ms   6.5ms
  • Specifications Bare dimension 724mm*511*209mm   724mm*511*209mm   724mm*511*209mm   724mm*511*209mm
  •   N.W. 5.75kg   5.75kg   5.75kg   TBD
  •   G.W. 7.97kg   7.97kg   7.97kg   TBD
  •   VESA Wall Mount 100mm*100mm   100mm*100mm   100mm*100mm   100mm*100mm
  • Input Interface VGA 1       1
  •   DVI 1(-D)   1(-D)   1(-D)
  •   HDMI 2(1.4)   1(1.4)   1(1.4)   2(1.4)
  •   DP   1(1.2)   1(1.2)   2(1.2+Mini1.2)
  •   PC-AUDIO 1
  • Output Interface Earphones 1   1   1   1
  • Special Functions Flicker-free Support   Support   Support   Support
  •   Blue-light filtering Support   Support   Support   Support
  •   Touching Nonsupport   Nonsupport   Nonsupport   Nonsupport
  • Accessory LED Monitor 1 PSC   1 PSC   1 PSC   1 PSC
  •   Base 1 PCS(Optional)   1 PCS(Optional)   1 PCS(Optional)   1 PCS(Optional)
  •   Power cord 1 PCS(VGA Cable)   1 PCS(HDMI Cable)   1 PCS(HDMI Cable)   1 PCS(HDMI Cable)
  •   Instructions 1 PCS   1 PCS   1 PCS   1 PCS
  •   Power cable/Adapter 1 PCS   1 PCS   1 PCS   1 PCS
  •
  •   Model U3203S Q3203SH Q3203SU
  •   Panel size 32" 32" 32"
  • Display parameters Backlight category ELED edge Type   ELED edge Type   ELED edge Type
  •   Panel UHD VA   QHD VA   QHD VA
  •   Aspect ratio 16:9   16:9   16:9
  •   Color Gamut 80%NTSC(95%Optional)     72%
  •   Resolution 3840*2160   2560*1440   2560*1440
  •   Resfresh rate 60Hz   144Hz   165Hz
  •   Viewing angle H:178°/V:178°(CR>10)   H:178°/V:178°(CR>10)   H:178°/V:178°(CR>10)
  •   Brightness 250-300cd/m²   200-250cd/m²   250-300cd/m²
  •   Contrast ratio 1000:1   3000:1   3000:1
  •   Response time 9.5ms   22ms   20ms
  •   Response time(With OD) 5.5ms   6ms   6ms
  • Specifications Bare dimension 724mm*511*209mm   724mm*511*209mm   724mm*511*209mm
  •   N.W. TBD   TBD   TBD
  •   G.W. TBD   TBD   TBD
  •   VESA Wall Mount 100mm*100mm   100mm*100mm   100mm*100mm
  • Input Interface VGA
  •   DVI 1
  •   HDMI 2(2.0+1.4)(HDCP1.4)   2(2.0)   2(2.0)
  •   DP 1(1.2)   2(1.2)   2(1.2)(1@144Hz+165Hz)
  •   PC-AUDIO 1
  • Output Interface Earphones 1   1   1
  • Special Functions Flicker-free Support   Support   Support
  •   Blue-light filtering Support   Support   Support
  •   Touching Nonsupport   Nonsupport   Nonsupport
  • Accessory LED Monitor 1 PSC   1 PSC   1 PSC
  •   Base 1 PCS(Optional)   1 PCS(Optional)   1 PCS(Optional)
  •   Power cord 1 PCS(HDMI Cable)   1 PCS(HDMI Cable)   1 PCS(HDMI Cable)
  •   Instructions 1 PCS   1 PCS   1 PCS
  •   Power cable/Adapter 1 PCS   1 PCS   1 PCS
Remarks: KTC will provide the information as correct as possible. Product photos on this website may vary from the real products. Products information may vary from the products manual available in the market. Please use the products subjected to the specific information on the user manual. For details, please contact the related persons.
